5.3.1 Establishing the Configuration Task
5.3.2 Checking Network Connectivity Through the Ping Operation
5.3.3 Locating Faults on the Network Through the Tracert Operation
5.3.1 Establishing the Configuration Task
Application Environment
The Customer Edge (CE) connected to the S9300 cannot access the Internet. You need to run
the ping and tracert commands to check network connectivity.
Pre-configuration Tasks
Before performing ping and tracert operations, complete the following tasks:
l Checking the physical connections between the CE and the S9300
l Correctly configuring an IP address for the CE device
Data Preparation
To perform ping and tracert operations, you need the following data.
No.
Data
1 IP address of the CE device
2 IP address of the gateway
5.3.2 Checking Network Connectivity Through the Ping Operation
Context
Do as follows on the S9300:
Procedure
Step 1 Run:
ping [ ip ] [ -a source-ip-address | -c count | -d | -f | -h ttl-value | -i
interface-type interface-number | -m time | -n | -p pattern | -q | -r | -s
packetsize | -t timeout | -tos tos-value | -v ]
*
host
Network connectivity is tested.
Only some of the parameters are specified in the preceding ping command. For details on more
parameters, refer to the Quidway S9300 Terabit Routing Switch Command Reference.
The output of the ping command is as follows:
l Response to each ICMP Echo Request message: If no Echo Reply message is received within
a certain period, a message of "Request time out" is displayed in the output. Otherwise, the
5 Ping and Tracert
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management
5-4 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2010-09-20)
