Step 3 Run:
test-type lspping
The test type is set to LSP Ping.
Step 4 Run:
lsp-type ipv4
The tunnel type is set to be the LSP tunnel.
Step 5 Run:
destination-address ipv4 ip-address { lsp-masklen masklen | lsp-loopback loopback-
address }*
The destination IP address to be tested is configured.
Step 6 (Optional) Perform the following as required to configure other parameters for the LSP Ping
test:
l To configure the response mode of the Echo packet, run the lsp-replymode { no-reply |
udp | udp-via-vpls | udp-router-alert | level-control-channel } command.
NOTE
In a uni-directional LSP Ping test, if the lsp-replymode no-reply command is configured, the test
result displays that the test fails regardless of whether the test, actually, is successful or fails. If the test
is successful, the test result also displays the number of the timeout packets. If the test fails, the test
result displays the number of the discarded packets.
l To configure the source IP address, run the source-address ipv4 ip-address command.
l To configure the packet size, run the datasize size command.
NOTE
The sum of datasize and the size of the packet header should be less than the MTU of the interface;
otherwise, the test may fail.
l To configure the maximum TTL value of the packet, run the ttl number command.
l To configure the LSP EXP value, run the lsp-exp exp command.
l To configure the padding character of the packet, run the datafill fillstring command.
l To configure the interval for sending test packets, run the interval seconds interval
command.
l To configure the percentage of the failed NQA tests, run the fail-percent percent command.
Step 7 Run:
start
The NQA test is started.
Select the start mode as required because the startcommand has several forms.
l To perform the NQA test immediately, run the start now [ end { at [ yyyy/mm/dd ]
hh:mm:ss | delay { seconds second | hh:mm:ss } | lifetime { seconds second | hh:mm:ss } } ]
command.
The test instance is started immediately.
l To perform the NQA test at the specified time, run the start at [ yyyy/mm/dd ] hh:mm:ss
[ end { at [ yyyy/mm/dd ] hh:mm:ss | delay { seconds second | hh:mm:ss } | lifetime
{ seconds second | hh:mm:ss } } ] command.
The test instance is started at a specified time.
