The list of cluster member:
------------------------------------------------------------------------------
SN Device Type MAC Address Status Device Name
------------------------------------------------------------------------------
0 S9300 0001-0001-0001 Admin HUAWEI_0.Administrator-1
1 S9300 0002-0002-0002 Up HUAWEI_1.Member-1
2 S9300 0003-0003-0003 Up HUAWEI_2.Member-2
3 S9300 0004-0004-0004 Up HUAWEI_3.Member-3
Step 7 Assign an IP address to VLANIF 10.
# To ensure the normal communication between member switches in the cluster and devices out
of the cluster, assign an IP address to VLANIF 10 on the administrator switch.
# Assign an IP address to VLANIF 10.
[HUAWEI_0.Administrator-1] interface vlanif 10
[HUAWEI_0.Administrator-1-Vlanif10] ip address 1.0.0.1 8
[HUAWEI_0.Administrator-1-Vlanif10] quit
After the previous configuration, you can find that the interface on the administrator switch is
in the Up state.
[HUAWEI_0.Administrator-1] display interface Vlanif 10
Vlanif10 current state : UP
Line protocol current state : UP
Last line protocol up time : 2008-09-25 21:25:52
Description:HUAWEI, Quidway Series, Vlanif10 Interface
Route Port,The Maximum Transmit Unit is 1500
Internet Address is 1.0.0.1/8
Internet Address is 10.0.0.1/8 Cluster
IP Sending Frames' Format is PKTFMT_ETHNT_2, Hardware address is 0001-0001-0001
Last 300 seconds input rate 0 bits/sec, 0 packets/sec
Last 300 seconds output rate 0 bits/sec, 0 packets/sec
Input: 0 packets, 0 bytes
Output: 0 packets, 0 bytes
Input bandwidth utilization : --
Output bandwidth utilization : --
Step 8 Configure a static route on the administrator switch.
# This operation is to ensure that a reachable route exists between switches in the cluster and
servers or hosts.
[HUAWEI_0.Administrator-1] ip route-static 0.0.0.0 0 1.0.0.2
NOTE
You can also run a routing protocol.
Step 9 Configure routes for the member switches and ensure that reachable routes exist between
member switches and the FTP server.
# Configure member switch 1.
[HUAWEI_1.Member-1] ip route-static 2.0.0.0 8 10.0.0.1
# Configure member switch 2.
[HUAWEI_2.Member-2] ip route-static 2.0.0.0 8 10.0.0.1
# Configure member switch 3.
[HUAWEI_3.Member-3] ip route-static 2.0.0.0 8 10.0.0.1
8 HGMP Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management
8-60 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2010-09-20)
