990400 Rev C 2010 May 1
Quality Assurance
12-3
9. Click Preview to check the phantom position.
The X-ray device may be dangerous to the Patient and operator if
you do not observe and follow the operating instructions. Do not
operate this system unless you have received training to perform a
procedure.
10. Click OK and press the Scan button on the Control Box when
prompted. An audible alarm is sounded and the X-ray ON light
is illuminated during radiation exposure.
11. The Phantom Platform must appear below the Field of View and
the Phantom must be centered. Adjust the Phantom Platform to
achieve the proper height.
12. To move the phantom to the right or left, use the Back / Front
feature.
If required, make adjustments and click Preview again. Repeat
as required.
The X-ray device may be dangerous to the Patient and operator if
you do not observe and follow the operating instructions. Do not
operate this system unless you have received training to perform a
procedure.
13. Click Capture to start the scan process.
14. Click OK and press the Scan button on the Control Box when
prompted. An audible alarm is sounded and the X-ray ON light
is illuminated during radiation exposure.
15. When the scan is completed, the image will load in the
Panoramic View.
16. If displayed, select Cancel at the Contourline Setup prompt.
