Imaging Sciences i-Cat 17-19 - Page 244

17-19 Operators’ Manual
990400 Rev C 2010 May 1
B-12
NOTE: Remember that the 3D data is calculated using the boxed
or freehand selected areas of interest in the Axial, Coronal &
Sagittal views. In this sample, the entire volume data is selected
in all 3 views.
Below is a sample of a 3D image calculated from the selected
volume area seen below.
In this sample,
only a portion of
the volume data
is boxed, which
is reflected in the
3D image
