RADAR 3.50
REFERENCE
173
Shortcut keys:
Session Controller
KC-24
Digital devices need a clock to operate. For stand-alone
operation the device itself usually derives the clock signal
from an internal master clock. However, when
interconnecting with other digital devices it becomes
necessary to have a master clock that provides timing
information to all the connected devices so that they can
communicate properly. RADAR provides the following
digital synchronization options:.
Possible clock reference sources are:
• INTERNAL
• WORDCLOCK
• VIDEO
• SMPTE
• MTC
• AES 2-CH SYNC
• S/PDIF 2-CH SYNC
• AES MULTI-CH
• ADAT
• TDIF L/R IN
• TDIF WORD SYNC
• MADI (Coaxial or Optical)
One of these options can be selected in the SYNC
REFERENCE dialogue and will remain selected until the
unit is powered down or rebooted. For further information
refer to CONFIGURATION: SYNC REFERENCE.
A 9-pin cable allows two or more RADAR units to be
connected and operated as a single unit. See
OPERATIONS: RADARLINK for further information.
Shortcut keys:
Session Controller or
KC-24
This dialogue is used to enable or disable RADARLink
operation.
RADARLINK:
ENABLE/DISABLE
MAIN/SYNC MENU:
RADARLINK
MAIN/SYNC MENU:
SYNC REFERENCE
