Johnson Controls CK721-A User Manual

CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-5
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
User Defined
Fields
(abbreviation:
User Def.)
Parameters that do not have pre-set options require that you
type in a value using the laptop or PC keyboard.
<Esc> Close a menu without saving changes.
<Save> Write the current record to the datab
ase. Use the arrow keys to
select this option and press <Enter>.
<Delete> Remove the current record from the da
tabase. Use the arrow
keys to select this option and press <Enter>.
<Previous
Record>
Move to the previous record in the
database for viewing or
editing. Use the arrow keys to select this option and press
<Enter>.
<Next Record> Move to the next record in the database for viewing
or editing.
Use the arrow keys to select this option and press <Enter>.
<Page Up> Move to the previous page of a multi-page screen.
Use the
arrow keys to select this option and press <Enter>.
<Page Down> Move to the next page of a multi-page screen. Use the arrow
keys to
select this option and press <Enter>.
<Execute
Comma
nd>
In some cases, such as Control Output, you will want to execute
a command immediately. Select this option, when available, and
press <Enter> to execute a command.
<Cal.> The Calibrate command issued from the U
ser Interface (see the
screen on page 4-72) will initiate input calibration at the
S300-DIN module. When the S300-
DIN module completes its
calibration, typically within a few seconds, the panel will send a
transaction message to the Real Time List indicating the
calibration result. After a successful calibration, four-state input
statuses will be available for the input point.
During the entire input calibration procedure
, the input’s contact
must be physically closed. Otherwise, the input’s status will be
unreliable.
Once you perform a calibration pro
cedure on an input, you
should not use this feature again, unless you change the
controller hardware or the input point’s wiring.
<CalRes.> The Uncalibrate command issued from the User Interface (see
th
e screen on page 4-72) will initiate calibration of selected
inputs using the resistor connected across CAL terminals. This
command is us
ed with the S300-DIN modules.
