Figure 3-1: S300-L
CK721-A Installation and Operation S300 Expansion Enclosures
24-10349-8 Rev. B 3-3
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
S300-XL (S300 Expansion Enclosure, Large)
S300-XL contains a power supply, a tamper switch, a power indicator light, and a
lock.
Power Supply
Tamper Switch
Lock
21 inches
(53 cm)
5.5 inches
(14 cm)
16 inches
(41 cm)
Power
Indicator Light
