Page #213 background image
24-10349-8 Rev. B F-1
Appendix
F
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
USING A KEYPAD READER ON A PANEL A
The following sections describe how to invoke access requests, Air Crew access requests,
Timed Overrides, and Panel Card Events using a keypad reader.
There is a 15-second time out on keypads. Whenever the keypad is idle for more that 15
seconds, all keys entered so far will be ignored, and the entire key sequence needs to be
re-entered.
NOTE
Card ID (the badge number) can have up to 19 digits. However, the total
number of keys pressed for PIN and Card ID combined must not exceed 21.
INVOKING ACCESS REQUESTS FROM A KEYPAD
 To invoke access with Badge:
1. To be able to invoke access using a badge at any time, set the terminal’s PIN
Suppression Timezone to <0>. Otherwise, access will be granted only
during active timezones.
2. At the keypad reader, present the badge.
 To invoke access with PIN Only:
1. The terminal’s PIN Only flag must be set. PIN Only works exclusively with
5-digit algorithmic PINs.
2. Set the panel’s PIN Code Type to Algorithmic.
3. The panel’s 5 Digit Pin Code must be set to 5.
4. At the keypad reader, enter PIN, and press the # key.
 To invoke access with Card ID:
1. To be able to invoke access with Card ID at any time, set the terminal’s PIN
Suppression Timezone to <0>. Otherwise, access will be granted only
during active timezones.
2. The terminal’s Card ID flag must be set.
3. Make sure the terminal’s PIN Only flag is not set.
