Modules
See the table below for a description of reader and I/O modules.
Table 1-3: Hardware Modules
Model Number Description
S300-DIN Modules
S300-DIN-RDR8S Stand-alone unit with removable connectors which can be
mou
nted on a DIN rail or on a flat surface. The unit
supports up to eight readers.
This module is also refe
rred to as the RDR8S.
S300-DIN-I32O16 Stand-alone unit with removable connectors which can be
mou
nted on a DIN rail or on a flat surface. The unit
supports up to 32 4-state inputs and 16 outputs.
This module is also referred to as the I32O16.
S300-DIN-RDR2SA Stand-alone unit with removable connectors which can be
m
ounted on a DIN rail or on a flat surface.The unit
supports up to two readers.
This module is also referr
ed to as the RDR2S-A.
S300-DIN-I8O4 Stand-alone unit with removable connectors which can be
mou
nted on a DIN rail or on a flat surface. The unit
supports up to 8 4-state inputs and 4 outputs.
This module is also referred to as the I8O4.
S300-DIN-RDR2S Stand-alone RDR2S unit which can be mounted on a DIN
r
ail or on a flat surface.
This module is also refe
rred to as the RDR2S.
S300 Modules
S300-RDR2 Two reader interfaces per module.
This module is also refe
rred to as the RDR2.
S300-I16 Sixteen 2-state inputs.
This module is also referred to as the I16.
S300-IO8 Eight 2-state inputs a
nd eight outputs.
This module is also referred to as the IO8.
S300-SIO8 Eight 4-state inputs a
nd eight outputs.
This module is also referred to as the SIO8.
S300-SI8 Eight 4-state inputs.
This module is also referred to as the SI8.
