Figure 3-27: S300-I16 Module
CK721-A Installation and Operation S300 Expansion Enclosures
24-10349-8 Rev. B 3-41
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
S300-I16 Unsupervised Input Module
The S300-I16 module provides:
 16 two-state input points
 16 red LED indicators which illuminate when each input is in alarm
J3
J2
RX
TX
5V 12V
SW1
J4D
J4C
J4B
J4A
16
U3
J1D
J1C
J1B
J1A
