CK721-A User Interface CK721-A Installation and Operation
4-76 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
When you enter a Timezone number, the Timezone window is displayed.
Card Events
This screen establishes an event based on card or badge (trigger) activity. The
purpose (action) of this window is to allow a person at a reader terminal to suppress
or unsuppress an input group, activate or deactivate an output group, operate a door
strike, and/or reset a panel alarm relay.
Card events will only activate as a result of a card transaction
decision made locally
at a panel. If the server performs the access transaction processing (in central or
shared mode), the card event will not occur.
Table 4-26: Time Zone Screen, 1 Page Only
Field Type Description
Time Zone Name User Def. Enter up to 25 alphanumeric characters as a
de
scriptive name for the time zone.
Output Group User Def. Enter the output group to which you want this
time zone applied.
(optional)
Midnight,
A
ctive/Inactive
Toggle Select midnight as inactive or active as the first
entry for a listed day or holiday.
Start/Stop Times User Def. Use the arrow keys to navigate through the
st
art and stop times, typing in the appropriate
values where required.
