CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-35
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
RDR2S-A Input Point and Output Point Disassociation
This feature allows RDR2S-A reader terminal input/output (I/O) points to be
re-assigned from reader-specific functions to general purpose I/O points.
NOTE
This feature requires RDR2S-A firmware version PS-217E-2
or higher.
The following RDR2S-A reader terminal outpu
t points can be re-assigned:
 Red LED
 Green LED
 Reader Strike
 Reader Shunt
The following RDR2S-A reader terminal input
points can be re-assigned:
 Reader Door Contact (door is always reported closed by Soft Alarm Points 18
and 24)
 Reader REX
Re-assignment of the special RDR2S-A reader terminal o
utput points to general
purpose output points is done by configuring the general purpose output points listed
in the following table:
Reader Output Point Terminal Output Point Number
Red LED Output 1 [Open Collector Output]
G
reen LED Output 2 [Open Collector Output]
Re
ader Shunt Output 3 [Relay Output]
Reader Strike Output 5 [Relay Output]
Re-assignment of the special RDR2S-A reader terminal input points to general
purpose input points is done by configuring the general purpose input points listed in
the following table:
Reader Input Point Terminal Input Point Number
Reader Door Contact Input 1
Reader REX Input 2
