CK721-A Installation and Operation Using a Keypad Reader on a Panel
24-10349-8 Rev. B F-5
This document contains confidential and proprietary information of Johnson Controls, Inc.ï€
© 2012 Johnson Controls, Inc.
6. To stop Timed Override:
Without the Star Feature, enter PIN, press the star (*) key, enter 0 (for
minutes), and present the badge.
With the Star Feature, enter PIN, press the star (*) key followed by number 0,
and present the badge.
 To invoke Timed Override with PIN and Badge, allowing PIN after
badge:
1. The terminal’s Cardholder Override flag must be set.
2. The badge’s Override flag must be set.
3. The terminal’s PIN Suppression Timezone must be set to an inactive zone.
4. The terminal’s Allow PIN After Badge flag must be set.
5. To start Timed Override:
Without the Star Feature, enter PIN, press the star (*) key, enter number of
minutes, present the badge
1
, and press the # key.
With the Star Feature, enter PIN, press the star (*) key followed by number 0,
enter number of minutes, present the badge
1
, and press the # key.
6. To stop Timed Override:
Without the Star Feature, enter PIN, press the star (*) key, enter 0 minutes,
present the badge
1
, press the # key.
With the Star Feature, enter PIN, press the star (*) key followed by number 0,
present the badge
1
, and press the # key.
1
The badge can be presented at any time before the # key is pressed.
INVOKING PANEL CARD EVENTS FROM A KEYPAD
 To invoke Panel Card Events with Badge:
1. The event’s Trigger Type must be set to Card/Keypad Code.
2. To be able to invoke a Panel Card Event using a badge at any time, set the
terminal’s PIN Suppression Timezone to <0>. Otherwise, the Panel Card
Event will be invoked only during active timezones.
3. To activate event:
Without the Star Feature, press A, enter the keypad code, and present the
badge.
With the Star Feature, press the star (*) key followed by number 1, enter the
keypad code, and present the badge.
