Using a Keypad Reader on a Panel CK721-A Installation and Operation
F-6 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
4. To deactivate event:
Without the Star Feature, press D, enter the keypad code, and present the
badge.
With the Star Feature, press the star (*) key followed by number 4, enter the
keypad code, and present the badge.
 To invoke Panel Card Events with PIN Only:
1. The event’s Trigger Type should be set to Card/Keypad Code or
Card/PIN/Keypad Code.
2. If set to Card/PIN/Keypad Code, the terminal’s PIN Suppression
Timezone must be set to an inactive timezone.
3. The terminal’s PIN Only flag must be set. PIN Only works exclusively with
5-digit algorithmic PINs.
4. Set the panel’s PIN Code Type to Algorithmic.
5. The panel’s 5 Digit Pin Code must be set to 5.
6. To activate event:
Without the Star Feature, enter PIN, press A, enter the keypad code, and press
the # key.
With the Star Feature, enter PIN, press the star (*) key followed by number 1,
enter the keypad code, and press the # key.
7. To deactivate event:
Without the Star Feature, enter PIN, press D, enter the keypad code, and press
the # key.
With the Star Feature, enter PIN, press the star (*) key followed by number 4,
enter the keypad code, and press the # key.
 To invoke Panel Card Events with Card ID:
1. The event’s Trigger Type must be set to Card/Keypad Code.
2. To be able to invoke a Panel Card Event using Card ID at any time, set the
terminal’s PIN Suppression Timezone to <0>. Otherwise, the Panel Card
Event will be invoked only during active timezones.
3. The terminal’s Card ID flag must be set.
4. Make sure the terminal’s PIN Only flag is not set.
5. Make sure the terminal’s “PIN + Card ID flag is not set.
6. To activate event:
Without the Star Feature, enter the Card ID number, press A, enter the keypad
code, and press the # key.
With the Star Feature, enter the Card ID number, press the star (*) key
followed by number 1, enter the keypad code, and press the # key.
