CK721-A Installation and Operation Using a Keypad Reader on a Panel
24-10349-8 Rev. B F-7
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
7. To deactivate event:
Without the Star Feature, enter the Card ID number, press D, enter the keypad
code, and press the # key.
With the Star Feature, enter the Card ID number, press the star (*) key
followed by number 4, enter the keypad code, and press the # key.
 To invoke Panel Card Events with PIN and Card ID:
1. The event’s Trigger Type should be set to Card/Keypad Code or
Card/PIN/Keypad Code.
2. If set to Card/PIN/Keypad Code, the terminal’s PIN Suppression
Timezone must be set to an inactive timezone.
3. The terminal’s PIN + Card ID flag must be set.
4. Make sure the terminal’s PIN Only flag is not set.
5. To activate event:
Without the Star Feature, enter PIN, enter the Card ID number, press A, enter
the keypad code, and press the # key.
With the Star Feature, enter PIN, enter the Card ID number, press the star (*)
key followed by number 1, enter the keypad code, and press the # key.
6. To deactivate event:
Without the Star Feature, enter PIN, enter the Card ID number, press D, enter
the keypad code, and press the # key
.
With the Star Feature, enter PIN, enter the Card ID number, press the star (*)
key followed by number 4, enter the keypad code, and press the # key.
 To invoke Panel Card Events with PIN and Badge:
1. The event’s Trigger Type must be set to Card/Keypad Code or
Card/PIN/Keypad Code.
2. The terminal’s PIN Suppression Timezone must be set to an inactive
timezone.
3. Make sure the terminal’s Allow PIN After Badge flag is not set.
4. To activate event:
Without the Star Feature, enter PIN, press A, enter the keypad code, and
present the badge.
With the Star Feature, enter PIN, press the star (*) key followed by number 1,
enter the keypad code, and present the badge.
5. To deactivate event:
Without the Star Feature, enter PIN, press D, enter the keypad code, and
present the badge.
With the Star Feature, enter PIN, press the star (*) key followed by number 4,
enter the keypad code, and present the badge.
