Additional Equipment
See Table 1-4 for a description of batteries and their corresponding bracket kits,
power supplies, transformer, and parts accesso
ry kit.
Table 1-4: Additional Equipment
Model Number Description
S300-BAT Battery for uninterruptible power operation, 12 volts, 7Ah.
Fo
r use in expansion enclosures and S300-DIN-L (two
backup batteries are used per enclosure).
S300-DIN-BRK Battery bracket kit for either S3
00-DIN-L or S300-DIN-S.
S300-BAT-2.8AH 12V, 2.8Ah battery for S300-DIN-S (two backup batteries are
u
sed per enclosure).
S300-BRK2 Battery bracket kit, b
racket with mounting hardware, and
interconnecting cable for installing S300-BAT to inside of
door of expansion enclosures.
S300-XFMR 120 VAC to 24 VAC plug-in transformer. Required for
S30
0-DIN-S and expansion enclosures.
S300-DIN-L-PS Power supply, 24VDC out, 110/220VAC 50/60Hz in.
S300-DIN-S-PS Power supply, 24VDC out, 24VAC in.
S300-PS Power supply, 5VDC/12VDC out, 24VAC in.
S300-DIN-PA1 Parts Accessory Kit. Contains a DC power harness, a lock, a
ta
mper switch, and two spare connectors (3-position and
4-position).

Johnson Controls CK721-A Specifications

General

Brand	Johnson Controls
Model	CK721-A
Category	Controller
Language	English
