Johnson Controls CK721-A User Manual

24-10349-8 Rev. B 3-1
Chapter
3
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
S300 EXPANSION ENCLOSURES
This chapter provides information on S300 expansion enclosures and accessories, as well as
their installation. It also describes legacy hardware modules used with CK721-A.
For details on configuring the modules for the expanded address S300 bus configuration see
the following documentation:
 Appendix A of this manual
 P2000 Software User Manual for P2000 v.3.10 or higher
 S300-DIN-RDR2S Hardware Installation Manual
 S300-DIN-RDR8S and S300-DIN-I32O16 Hardware Installation Manual
 S300-DIN-RDR2SA and S300-DIN-I8O4 Hardware Installation Manual
 S300-DIN-RDR2SA Address Mode Configuration Technical Bulletin
S300 EXPANSION ENCLOSURES
The S300 expansion enclosures are used to host additional modules in the CK721-A system.
They cannot, however, be used with the CK721-A controller itself, because they do not have
the DIN rails necessary for its mounting.
Installing the Expansion Enclosures
Before beginning, take a moment to read the following important notes. Careful
adherence to the procedures and important notes in this manual will help ensure the
successful installation and operation of your system.

Johnson Controls CK721-A Specifications

General

Brand	Johnson Controls
Model	CK721-A
Category	Controller
Language	English
