CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-43
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
Floor Grant Output. An access granted message (floor number, cab number,
badge number, time, and access granted) is then sent up to the host and the
green reader indicator is lit momentarily.
 If the floor call request is not within the privileges associated with the badge,
an access denied message is sent to the host (floor number, cab number,
badge number, time, and invalid floor) and the red indicator is lit
momentarily.
 If the time zone for the floor call requested is not within the privileges
associated with the badge, an access denied message is sent to the host (floor
number, cab number, badge number, time, and invalid time zone) and the red
indicator is lit momentarily.
 If the badge is not valid, an access denied message is sent to the host (floor
number, cab number, badge number, time, and invalid card) and the red
indicator is lit momentarily.
 If there are no floor call requests queued, no further action is taken.
KONE HLI/KONE ELINK High Level Interface
The KONE interface is a master slave protocol over RS232 or RS485, according to
KONE Elevator EPL HLI Security Protocol specification V=2.3
SO-13.20.10-KAM, with the CK721-A being the master.
Each panel connects to a KONE group controller with up to 8 elevators, with each
elevator serving up to 64 floors. Connect the elevator
interface to RS232C B (J2) of
the CK7
21-A.
The panel’s name has to start with a chara
cter between “1” and “8”, specifying the
KONE group controller’s address. An incorrect setting will not permit the
integration to be operational. The second character of the panel’s name needs to be
an “H” if the connection is to run at 9600 baud, otherwise the connection runs at
1200 baud. The 3rd and the 4th character of the panel’s name need to be in the range
of ASCII characters “01” through “64” with leading zeros. This value specifies the
lowest level of the building served by any KONE elevator in this KONE group
controller. An incorrect setting will secure and de-secure floors other than those
intended.
To define a KONE elevator, the High Level Interface flag has to be checked, and
the
protocol field has to be set to 1 or KONE HLI. The elevator’s name has to start with
a character between “1” and “8”, specifying the KONE elevator address inside the
KONE group controller.
To define the floors of a KONE elevator,
the public access timezone must be
defined, but there should be no output or input points associated with the floor. A
floor is on public access when the specified timezone is active. A floor is not on
public access when the specified timezone is inactive.
The rest of this integration is identical
to the low level elevator interface.
