CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-79
This document contains confidential and proprietary information of Johnson Controls, Inc.ï€
© 2012 Johnson Controls, Inc.
Table 4-29: Card Event Screen, Page 2
Field Type Description
Trigger Type Toggle Card/PIN/Keypad Codeï€
Enter PIN and activation or deactivation code,
follo
wed by the code specified in the Keypad
Code field, then present a card. For detailed
instructions refer to Appendix F. ï€
ï€
Any Void Cardï€
Present any invalid card. In t
his case the card
event’s privilege level should be set to 0, as
invalid cards do not have any privilege level.ï€
ï€
Special Access (A, B or C)
Present a card with assigned Special Access flag
A, B,
or C.
Event Privilege
Level
User Def. Assign a privilege level to this event. Values
r
anges from 0 to 7, with 7 being the highest
privilege level. This number corresponds to the
Event Privilege Level field in the Badge screen,
where a badge can execute an event equal to or
less than its privilege value.
Keypad Code User Def. Enter up to a four-digit keypad code required to
activate or
deactivate this event when using a
keypad trigger type. Deactivating an event can
only be accomplished by using a keypad code.
For detailed instructions refer to Appendix F.
Output Group
En
able
Toggle If enabled (Y), an output group specified by the
Output Group field will be enabled. Outputs in
the group will behave according to their defined
active state.
Set Output Group To g g le Enable (Y) to act
ivate the specific output group
when this event is activated. Disable (N) to
deactivate the specific Output Group when this
event is activated. When this event is
deactivated, the selected action is inverted: an
event that activates an output group on
activation, deactivates that output group on
deactivation; and an event that deactivates an
output group on activation, activates that output
group on deactivation.
