CK721-A User Interface CK721-A Installation and Operation
4-14 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
Primary Host
IP Address
User Def. The primary IP address used by the primary
server network interface. An IP address is a 32-bit
number that is notated by using four numbers
from 0 through 255, separated by periods. To
clean the IP entry, enter the IP value of
000.000.000.000.
Note: Pr
ior to entering the address, the panel
must be defined in the P2000 database.
Alternate Host
IP Address
User Def. This IP address is reserved for future use in
support
of a secondary IP interface.
Preferred
Pr
imary
Comm Path
Toggle Enabled (Y) by default. The CK721-A will
communicate via onboard network interface.
Network Polling
(LAN)
User Def. Specifies the maximum time (in seconds) the
p
anel allows between consecutive polls to the
server over the LAN connection.
The network poll (LAN) interval is limi
ted to values
between 5 seconds and 30 days.
Network Polling
(Dup
)
User Def. The Dialup connection polling is not currently
used.
Download Port
Nu
mber (1 to
65535)
User Def. A TCP port number used for downloads from the
server.
This number must match that configured at the
ser
ver. See step 6 on page 4-11 for details.
Upload Port
Nu
mber (1 to
65535)
User Def. A TCP port number used for uploads to the
server.
This number must match that configured at the
ser
ver. See step 6 on page 4-11 for details.
Priority Port
Nu
mber (1 to
65535)
User Def. A TCP port number used for sending central
access requests and for transactions confirming
the panel and the server are online.
This number must match that configured at the
ser
ver. See step 6 on page 4-11 for details.
High Speed 485 Toggle When enabled (Y)
, causes the CK721-A to
communicate with the terminals at 19,200 baud.
For information on firmware version required for
High
Speed RS485, see page 3-38.
Table 4-3: Panel Screen, Page 1
Field Type Description
