CK721-A User Interface CK721-A Installation and Operation
4-16 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
Delete History
Older Than Days
Toggle If enabled (Y), saved history records, older than
the specified number of days (see next field) will
be deleted.
Delete History
Olde
r Than Days
User Def History older than the specified number of days
will be deleted.
In order to work, this option must be enabled in
the
previous field.
Value range: 0 - 255 days
Delete History At User Def Specifies the hours and minutes at which the
saved his
tory deletion occurs.
In order to work, this option must be enabled in
the
“Delete History Older Than Days” toggle field.
Timed Override/
Anti-Tailgate
Toggle If enabled (Y)
, a reader controlled door, which is
in a state of Timed Override, may be locked
automatically when the door is closed.
This option should not be used with the “Re-lock
on
Door Open” option because “Timed
Override/Anti-Tailgate” can only work when the
door closes, and not when the door opens
(shunting of the door contact is cancelled at the
same time as “Timed Override/Anti-Tailgate” is
cancelled).
Alarm Latch 
Output
Toggle If enabled (Y),
the alarm relay is activated
whenever an input goes into alarm, and remains
activated until reset. If disabled (N), and “Activate
Relay when Set” under Input is enabled, the
panel alarm relay is activated whenever an alarm
occurs and deactivated when all alarms are reset.
Input Report
De
lay
User Def. Enter a value between 0 and 60 seconds.
Determines the number of seconds between an
input going active and when it is reported at the
panel.
Time Zone
Of
fset
User Def. Values are hours and minutes (HH:MM). Used if
the controller is physically in a different
geographical time zone than the P2000 server.
Entry/Exit Toggle If enabled (Y), r
eaders can enforce Entry/Exit
rules for access control.
PIN Code Type Toggle Choices are: Algorithmic, Custom (User Defined).
N Digit Pin Code User Def. For algorithmic PIN codes select 4 or 5 digits. For
custom PIN code
rs select 4 to 9 digits.
Table 4-4: Panel Screen, Page 2
Field Type Description
