CK721-A User Interface CK721-A Installation and Operation
4-40 24-10349-8 Rev. B
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
For configuration details, refer to the P2000 Software User Manual.
Global Badge Entry/Exit Status Synchronization
The Global Badge Entry/Exit Status Synchronization feature, when enabled in
P2000, allows the P2000 to interact with the controllers by providing badge status
synchronization across multiple controllers. It is not recommended for medium and
large systems.
IMPORTANT
This feature must never be combined with the Controller Peer-To-Peer
Global Entry/Exit Enforcement and Synchronization option selection.
Selecting both features will cause badge entry/exit enforcement errors
across multiple controllers.
Controller Badge Local Entry/Exit Enforcement
The CK721-A controller Local Entry/Exit enforcement feature limits a cardholder
Badge entry/exit status enforcement to a specific CK721-A controller and a
maximum of 64 readers (32 pairs of In/Out readers). Therefore, a cardholder badge
swiped on a reader terminal connected to one CK721-A controller would not have
their entry/exit privileges synchronized on a reader terminal connected to different
CK721-A controller.
Refer to the P200
0 Software User Manual for configuration details.
Controller Peer-To-Peer Global Entry/Exit Enforcement and
Synchronization
The controller Peer-To-Peer Global Entry/Exit enforcement feature allows a
CK721-A controller to broadcast the entry/exit status of a badge to multiple
CK721-A controllers via UDP protocol. This allows an Entry/Exit zone to span
across multiple CK721-A controllers within the same Subnet, or across multiple
Subnets using a properly configured multicast router. In addition, by changing the
controller Peer-To-Peer UDP Port Number, a new Entry/Exit zone, spanning
multiple CK721-A controllers can be created.
This feature requires P2000 version 3.8 Build 55 or higher.
IMPORTANT
This feature must never be combined with the Global Badge Entry/Exit
Status Synchronization. Selecting both features will cause badge
entry/exit enforcement errors across multiple controllers.
