CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-49
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
6th character: Master.This character defines the poll delay that prevents the OTIS
equipment from being overloaded. A lower value speeds up the integration. A higher
value slows down the integration. Any invalid character uses the default poll delay
of 400 ms. Slave: Not used
7th character: Mas
ter. This character defines the how many times a message is
retried before OTIS is declared offline. Any invalid character uses the default
number of 3 retries. Slave: Not used
8th character: Mas
ter & Slave. This character defines the priority of the OTIS
integration within a CK721-A controller. This setting should not be changed unless
after consultation with Technical Support. Any invalid character uses the default
priority of 19.
All subsequent charac
ters can be freely chosen.
Example 1:
“(9D5) Controller XYZ” defines a master panel that uses a 200
ms OTIS timeout, a
400 ms poll delay, and 3 retries. The OTIS integration uses groups 1, 3, 4, 5 and 8,
and the elevator with the most landings has between 33 and 40 landings. No change
to the priority was made.
Example 2:
“(9D5128) Controller XYZ” defines a master panel that uses
a 100 ms OTIS
timeout, a 200 ms poll delay, and 8 retries. The OTIS integration uses groups 1, 3, 4,
5 and 8, and the elevator with the most landings has between 33 and 40 landings. No
change to the priority was made. This OTIS integration runs faster than the one in
example 1, but it exceeds OTIS's recommendation for the maximum rate of polling.
Elevator
In the P2000 user interface, select the protocol type for
the panel. Refer to the P2000
Software User Manual for detailed information.
5th character 1 2 3 4 5 6 7 8 9
Poll delay [ms] 0 100 200 300 400 500 600 700 800 900
6th character 0 1 2 3 4 5 6 7 8 9
Number of retries 0 1 2 3 4 5 6 7 8 9
7th character 0 1 2 3 4 5 6 7 8 9
Priority 10 11 12 13 14 15 16 17 18 19
8th character 0 1 2 3 N/A N/A N/A N/A N/A N/A
OTIS timeout [ms]
(M
aster only)
100 200 300 400 500 600 700 800 900
