1 Introduction
10
1.1.3 Display types
Menu structure
The > symbol between words indicates a menu structure and enables the parameters to be
quickly detected in the configuration level or for navigation in the setup program, such as the
software version of the devices, for example:
D
EVICE MENU >GENERAL >VERSION >SW VERSION
Active input
The device has no keys and is operated using a finger or a pen.
The following manual will therefore make references to "touching" and the images displayed
will show a hand operating the device.
FURTHER INFORMATION!
This symbol is used in the tables and refers to further information in connection with the
table.
DISPOSAL!
This device and the batteries (if installed) must not be disposed in the garbage can after
use! Please ensure that they are disposed properly and in an environmentally friendly
manner.
