JUMO DICON touch User Manual

4 Electrical connection
32
4.3.9 Digital outputs
Standard
Per optional board
4.3.10 Voltage supply (according to nameplate)
AC 230V (DC 24V)
Two relay outputs (changeover contact)
Switching capacity AC
Switching capacity DC
Contact life
AC 230V/24V; 3(0,5) A; cosφ=1(≥ 0,6); D300
DC 24V; 3(0,5; τ =7ms) A
250,000 operations at nominal load
One relay output (changeover contact)
Switching capacity AC
Switching capacity DC
Contact life
AC 230V/24V; 3(0,5) A; cosφ=1(≥ 0,6); D300
DC 24V; 3(0,5; τ =7ms) A
250,000 operations at nominal load
Two relay outputs (N/O contact)
1
Switching capacity AC
Switching capacity DC
Contact life
AC 230V/24V; 3(0,5) A; cosφ=1(≥ 0,6); D300
DC 24V; 3(0,5; τ =7ms) A
250,000 operations at nominal load
One solid state relay
Switching capacity
Protection circuitry
1 A at AC 230 V, resistive load
Varistor
Two solid state relay for motor actuators
Switching capacity
Protection circuitry
1 A at AC 230 V,
RC combination
One logic output
(voltage supply for transmitter)
DC 0/22 V, max. 30 mA (short-circuit proof)
Two logic outputs DC 0/12 V max. 20 mA (short-circuit proof, not galvanically isolated)
Two PhotoMOS® relays
2
DC 45 V, max. 200 mA, (galvanically isolated from each other, not
short-circuit proof)
AC 30 V, max. 200 mA, (galvanically isolated from each other, not
short-circuit proof)
1
Combining a mains voltage circuit with a protective low-voltage circuit on the "dual normally open contact" option is
not admissible.
2
PhotoMOS is a registered trademark of Panasonic Corporation.
