12 Configuration
12.18 External analog inputs
8 external analog inputs are available. The settings can be copied to another input using the
C
OPY button.
Setup dialog box
Parameters
Parameter Selection/settings Description
Description Ext. AI 01
Temperature None
Relative
Absolute
Comma format Auto Automatic switching
XXXXX. No decimal place
XXXX.X 1 decimal place
XXX.XX 2 decimal places
XX.XXX 3 decimal places
X.XXXX 4 decimal places
Meas. range start 0.0000
Meas. range end 100.00
Save Power-OFF No
Yes Status is saved beyond the power failure.
