3 Mounting
3.1 Mounting site and climatic conditions
The mounting site should be free from vibration, dust and corrosive media. Install controllers
as far away as possible from sources of electromagnetic fields, such as those created by fre-
quency converters or high-voltage ignition transformers. Conditions at the mounting site must
correspond to the following environmental influences:
3.1.1 Electrical data
3.1.2 Environmental influences
3.1.3 Housing
Voltage supply
Connection
Voltage
At the back via screw terminals
AC/DC 24 V +30/-25%, 48 to 63 Hz or AC 110 to 240 V +10/-15 %,
48 to 63 Hz
Power consumption At voltage supply 230 V: max. 15 VA / 7 W
At voltage supply 24 V: max. 12 VA / 9 W
Inputs and outputs
Connection
Conductor cross section
At the back via screw terminals
Max. 2.5 mm
2
, wire or strand with end sleeve
Electrical safety According to DIN EN 61010-1
Overvoltage category III, pollution degree 2
Electromagnetic compatibility
Interference emission
Interference immunity
According to DIN EN 61326-1
Class A - For industrial applications only
Industrial requirements
Memory data recorder (1 recording image) Memory cycle Recording interval
When recording:
4 analog signals
3 digital signals
1 s approx. 44 days
5 s approx. 220 days
10 s approx. 441 days
60 s approx. 2646 days (7 years, 91 days)
Note:
In case of recording 2 recording images, the recording intervals are cut in an half
Ambient/storage temperature range -5 to +55 °C/-30 to +70 °C
Resistance to climatic conditions Humidity 3K3 (DIN EN 60721-3-3) with extended temperature
range,
rel. humidity ≤ 95 % mid-year without condensation
Site altitude Maximum 2000 m above sea level
Case type Plastic front frame with metal case barrel (for indoor use)
Front frame dimensions 96 mm × 96 mm
Panel cut-out 92
+0.8
mm × 92+
0.8
mm according to DIN IEC 61554
