Fixed limit value
12.9.2 Hysteresis
The designations "Non-standard left" and "Non-standard right" typically relate to alarm func-
tions AF3/AF4 and AF7/AF8. The designation is not conclusive for alarm functions AF1/AF2
and AF5/AF6.
Ö Chapter 12.9.1 "Function and hysteresis", page 108
Non-standard left Symmetrically Non-standard right
AF5
AF6
w
(1)
x
0
(2)
w
(1)
x
0
(2)
w
(1)
x
0
(2)
w
(1)
x
0
(2)
w
(1)
(2)
x
0
w
(1)
(2)
x
0
1 Output signal active 0 Output signal not active
x Actual value w Setpoint value
(1) Limit value (setpoint value distance) (2) Hysteresis
Non-standard left Symmetrically Non-standard right
AF7
AF8
(1)
1
x
0
(2)
(1)
1
x
0
(2)
(1)
1
x
0
(2)
(1)
1
x
0
(2)
(1)
1
x
0
(2)
(1)
1
x
0
(2)
1 Output signal active 0 Output signal not active
x Actual value
(1) Limit value (2) Hysteresis
