JUMO DICON touch User Manual

4 Electrical connection
28
4.3.3 Probes for air
NOTE!
Approval according to DIN EN 14597 is only valid if the correct probe with DIN approval
is set in the configuration level, and also connected to the analog input. The measured
value acquired in this way must lie in the approved temperature range of the DIN probe
in the following tables, and can, for example, continue to be used as the actual value
for the two controllers or for the limit value monitoring function.
Hinweis: Wegen der Ansprechgenauigkeit ist die Verwendung nur ohne Schutzhülsen (Tauchhülsen) zulässig.
aktuelle Typenbezeichnung alte Typen-
bezeichnung
Fühlerart Temperaturbereich Nennlänge mm Prozessanschluss
Widerstandsthermometer Typenblatt 90.2006
902006/65-228-1003-1-15-500-668/000 - 1 x Pt100 -170 ... +700°C 500
902006/65-228-1003-1-15-710-668/000 - 710
902006/65-228-1003-1-15-1000-668/000 - 1000
902006/55-228-1003-1-15-500-254/000 - 1 x Pt100 -170 ... +700°C 500
902006/55-228-1003-1-15-710-254/000 - 710
902006/55-228-1003-1-15-1000-254/000 - 1000
902006/65-228-2003-1-15-500-668/000 90.271-F01 2 x Pt100 -170 ... +700°C 500 Anschlagflansch
verschiebbar
902006/65-228-2003-1-15-710-668/000 90.272-F01 710
902006/65-228-2003-1-15-1000-668/000 90.273-F01 1000
902006/55-228-2003-1-15-500-254/000 - 2 x Pt100 -170 ... +700°C 500 verschiebbare
Klemmverschraubung
G1/2
902006/55-228-2003-1-15-710-254/000 - 710
902006/55-228-2003-1-15-1000-254/000 - 1000
Thermoelemente Typenblatt 90.1006
901006/65-547-2043-15-500-668/000 90.019-F01 2 x NiCr-Ni, Typ „K“ -35 ... +800°C 500 Anschlagflansch
verschiebbar
901006/65-547-2043-15-710-668/000 90.020-F01 710
901006/65-547-2043-15-1000-668/000 90.021-F01 1000
901006/65-546-2042-15-500-668/000 90.019-F11 2 x Fe-CuNi, Typ „L“ -35 ... +700°C 500
901006/65-546-2042-15-710-668/000 90.020-F11 710
901006/65-546-2042-15-1000-668/000 90.021-F11 1000
901006/66-550-2043-6-500-668/000 90.023-F01 2 x NiCr-Ni, Typ „K“ -35 ... +1000°C 500
901006/66-550-2043-6-355-668/000 90.023-F02 355
901006/66-550-2043-6-250-668/000 90.023-F03 250
901006/66-880-1044-6-250-668/000 90.021 1 x PT10Rh-PT, Typ „S“ 0 ... 1300°C 250
901006/66-880-1044-6-355-668/000 90.022 355
901006/66-880-1044-6-500-668/000 90.023 500
901006/66-880-2044-6-250-668/000 90-D-021 2 x PT10Rh-PT, Typ „S“ 0 ... 1300°C 250 Anschlagflansch
verschiebbar
901006/66-880-2044-6-355-668/000 90-D-022 355
901006/66-880-2044-6-500-668/000 90-D-023 500
901006/66-953-1046-6-250-668/000 90.027 1 x PT30Rh-PT6Rh, Typ „B“ 600 ... 1500°C 250
901006/66-953-1046-6-355-668/000 90.028 355
901006/66-953-1046-6-500-668/000 90.029 500
901006/66-953-2046-6-250-668/000 90-D-027 2 x PT30Rh-PT6Rh, Typ „B“ 600 ... 1500°C 250
901006/66-953-2046-6-355-668/000 90-D-028 355
901006/66-953-2046-6-500-668/000 90-D-029 500
