107
12 Configuration
Position of hysteresis Symmetrically Here you can adjust the setting for which side the
hysteresis should be on.
Non-standard left
Non-standard right
Start-up alarm sup-
pression
Inactive AF switching behavior is not suppressed
Active AF switching behavior is suppressed, provided
that the value was not within the valid range.
Switch-On delay 0.0000 to 99999 Once the AF event has occurred, the time for the
switch-on delay begins to elapse.
The AF output remains unchanged at first until the
time set here has completely elapsed and the AF
event is relayed to the AF output.
If the AF actual value leaves the "bad range" dur-
ing this time for the switch-on delay, the count-
down begins again for each new limit value
violation.
Switch-off delay 0.0000 to 99999 Identical behavior as with switch-on delay, except
that the AF switch-off process is delayed. The
lock takes priority over the switch-off delay.
Pulse time 0.0000 to 99999 AF output is automatically deactivated after the
pulse time.
The output is only re-activated to the maximum
level via the set pulse time after repeated devia-
tion above or below the alarm values.
The lock takes priority over the pulse function.
Response at error
Off AF output is switched off in the event of an error
On AF output is switched on in the event of an error
Confirm
Off The alarm function is automatically reset following
a limit value violation.
"Inactive" status The lock can only be acknowledged if the AF
actual value is back in the valid range.
"Active" status The lock can always be acknowledged if it has
been activated
Signal acknowledge-
ment
No selection No acknowledgement possible
Digital selector This signal acknowledges the lock.
Signal Locked No selection The "Signal Locked" input can be used to set and
maintain the output signal of the limit value moni-
toring function at the logical value "0".
As a result, alarms will be suppressed.
This means:
As long as "1" is applied at the input for "Signal
Locked", the output of the limit value monitoring
function will always be "0"
Digital selector
Additional functions Not selected (empty)
(setup only) (⎫) Extension 1 Reserved functions for service
(⎫) Extension 2
(⎫) Extension 3
(⎫) Extension 4
Parameter Selection/settings Description
