JUMO DICON touch User Manual

2 Identifying the device version
14
11 1 relay (changeover contact)
12 2 relays (normally open)
13 1 solid state relay 230 V, 1 A
14 1 logic output 0/22 V, max. 30 mA
15 2 logic outputs 0/12 V, 20 mA
16 1 analog output
17 2 PhotoMOS® relays
1
(9) Outputs OUT9/10 (not available for assignment with module 20 on OUT5/6)
00 None
11 1 relay (changeover contact)
12 2 relays (normally open)
13 1 solid state relay 230 V, 1 A
14 1 logic output 0/22 V, max. 30 mA
15 2 logic outputs 0/12 V, 20 mA
16 1 analog output
17 2 PhotoMOS® relays
1
(10) Outputs OUT11/12
00 None
11 1 relay (changeover contact)
12 2 relays (normally open)
13 1 solid state relay 230 V, 1 A
14 1 logic output 0/22 V, max. 30 mA
15 2 logic outputs 0/12 V, 20 mA
16 1 analog output
17 2 PhotoMOS® relays
1
(11) Voltage supply
23 AC 110 to 240 V +10/-15 %, 48 to 63 Hz
39 AC/DC 24 V +30/-25 %, 48 to 63 Hz
(12) Interface COM2
00 Not used
08 Ethernet
54 RS422/485 Modbus RTU
63 PROFINET
64 PROFIBUS-DP
(13) DIN-tested
000 Without approval
056 With DIN approval
(14) DNV GL-tested
000 Without approval
062 With DNV GL approval
