12 Configuration
80
Control direction
Is set to inverse (1) per default for heating mode.
Manual mode
Enabled Manual mode possible on the device
Disabled Manual mode disabled
Y in manual mode Defines the output level (%) that the controller should
adopt after switching to manual mode.
Y manual mode The value set below for Y manual mode is adopted.
Current value The current controller output level before switching to
manual mode is adopted.
Average value The average value calculated using the set time below
is adopted.
Y with error Defines the output level (in %) that the controller should
display, if one of the analog values relevant for the con-
troller is invalid (incorrect actual value, setpoint value,
output level feedback, etc).
Y replacement value The Y replacement value set below is adopted.
Current value The current output level before deviation above or below
the measuring range is adopted.
Average value The average value calculated using the set time below
is adopted.
Y manual mode 0 to 100 %
Y replacement
value
0 to 100 %
Time for
manual aver-
age value
1 to 3600 min Time for averaging of values when average value is set
for "Y in manual mode"
Time for
replacement
average value
1 to 3600 min Time for averaging of values when average value is set
for "Y with error"
Start of cascade
standardization
0 to 100 % The output level can be standardized here (only for cas-
cade controllers).
End of cascade
standardization
0 to 100 %
Deadband
(neutral zone)
0.00 to 100 % Output level movements within the deadband are sup-
pressed, for example in the case of noisy signals. The
deadband is only effective for controller structures with
an I-component.
Additional functions Not selected (empty)
(setup only) (⎫) Extension 1 Reserved functions for service
(⎫) Extension 2
(⎫) Extension 3
(⎫) Extension 4
1
Bold: default setting
Parameter Selection/settings
1
Description
