CONFigure:TINTerval
Syntax
CONFigure:TINTerval [<channel(s)>]
Description
This command sets all measurement parameters and trigger parameters to default values for time interval
measurements on one channel or between two channels.
Parameters
Name Type Range of Values Default Value
<channel(s)> Expression(s) (@1),(@2) | (@2),(@1) |
(@1) | (@2)
(@1),(@2)
Remarks
l The input channel(s) are configured for auto-leveling at 50% with a positive slope.
l The gate source (see SENSe:TINTerval:GATE:SOURce) is set to IMMediate.
l After configuring a single-channel time interval measurement, you should change the start or stop
input thresholds (INPut{1|2}:LEVel{1|2} or INPut{1|2}:LEVel{1|2}:RELative commands) or slopes (INPut
{1|2}:SLOPe{1|2} command), or you should set a stop holdoff (SENSe:GATE:STOP:HOLDoff:SOURce).
Measurements made without changing at least one of these settings will result in values of approx-
imately 0 seconds.
l To configure a single-period measurement on a channel, use CONFigure:SPERiod.
l Use READ? or INITiate[:IMMediate] to start the measurement.
Examples
The following example configures the instrument for time interval measurements from channel 1 to chan-
nel 2, makes two measurements, and then transfers the measurements to the instrument output buffer.
CONF:TINT (@1),(@2)
SAMP:COUN 2
READ?
Typical Response: +5.10520000000000E-006,+5.10370000000000E-006
See Also
CONFigure?
INITiate[:IMMediate]
MEASure?
CONFigure:TINTerval
150 Keysight 53220A/53230A Programmer's Reference
