CONFigure:TOTalize:TIMed
Syntax
CONFigure:TOTalize:TIMed [{<gate_time> | MINimum | MAXimum | DEFault}] [,<channel>]
Description
This command sets all measurement parameters and trigger parameters to default values for timed total-
ize measurements.
Parameters
Name Type Range of Values Default Value
<gate_time> Numeric 100 usec to 1000 sec with
10 usec resolution
or +9.9E+37 (INFinity) (Keysight 53220A)
1 usec to 1000 sec with
1 usec resolution
or +9.9E+37 (INFinity) (Keysight 53230A)
MIN=100 usec (Keysight 53220A)
MIN = 1 usec (Keysight 53230A)
MAX=1000 sec
.1 sec
<channel> Expression (@1) | (@2) (@1)
Remarks
l The input channel is configured to use the current input threshold voltage and slope (see INPut:LEVel
and INPut:SLOPe) with auto-leveling disabled.
l The gate source (see SENSe:TOTalize:GATE:SOURce) is set to TIME and the gate time (see SENSe:TOTal-
ize:GATE:TIME) is set to the <gate_time> value.
l Use READ? or INITiate[:IMMediate] to start the measurement.
Examples
The following example configures the instrument for timed totalize measurements on channel 1 using
default parameters.
CONF:TOT:TIM
READ?
Typical Response: +5.10500000000000E+003
The following example configures the instrument for 1 second timed totalize measurements on channel 2.
CONFigure:TOTalize:TIMed
