Keysight 53230A - Sense:frequency:burst:gate:time

SENSe:FREQuency:BURSt:GATE:TIME
Syntax
[SENSe:]FREQuency:BURSt:GATE:TIME {<time> | MINimum | MAXimum | DEFault}
[SENSe:]FREQuency:BURSt:GATE:TIME? [{MINimum | MAXimum | DEFault}]
Description
This command selects the gate time for measuring the carrier frequency of a burst (pulse frequency) when
SENSe:FREQuency:BURSt:GATE:AUTO is set to OFF (manual gate control).
When manual control, the gate window must be fully within the pulse envelope; oth-
erwise, the measurement results will be unpredictable.
Parameters
Name Type Range of Values Default Value
<time> Numeric 1 usec to 1000 sec with
10 nsec resolution
MIN = 1 usec
MAX=1000 sec
1 usec
Remarks
l Available only on the Keysight 53230A. Requires option 150.
l The instrument sets the gate time to 1 usec after a Factory Reset (*RST command) or an Instrument Pre-
set (SYSTem:PRESet command).
Return Format
The query returns the gate time in the form +1.00000000000000E-007.
Examples
The following example measures the carrier frequency of a burst. The measurement starts 1 uS after the
burst starts with a gate time of 3 uS:
CONF:FREQ:BURS
FREQ:BURS:GATE:AUTO OFF
FREQ:BURS:GATE:DEL 1E-6
SENSe:FREQuency:BURSt:GATE:TIME
336 Keysight 53220A/53230A Programmer's Reference
