l The gate source (see SENSe:FREQuency:GATE:SOURCE) is set to TIME.
l
The counter uses the <expected> and <resolution> parameters to configure the setting for the
SENSe:FREQuency:GATE:TIME command. The table below shows the relationship between relative res-
olution and gate time in seconds, where relative resolution = <resolution> / <expected>.
Relative Resolution
Gate Time
(53220A)
Gate Time
(53230A)
≤ 1.1E-14 1000 sec 1000 sec
>1.1E-14 to ≤1.1E-13 1000 sec 100 sec
>1.1E-13 to ≤1.1E-12 100 sec 10 sec
>1.1E-12 to ≤1.1E-11 10 sec 1 sec
>1.1E-11 to ≤1.1E-10 1 sec 100 msec
>1.1E-10 to ≤1.1E-9 100 msec 10 msec
>1.1E-9 to ≤1.1E-8 10 msec 1 msec
>1.1E-8 to ≤1.1E-7 1 msec 100 usec
>1.1E-7 to ≤1.1E-6 100 usec 10 usec
>1.1E-6 100 usec 1 usec
Return Format
The query returns a single measurement. The format of the measurement is controlled by the FORMat
Subsystem commands.
Examples
The following example configures the instrument for average period measurements on channel 1 using
default parameters, makes one measurement, and then transfers the measurement to the instrument out-
put buffer.
MEAS:PER?
Typical Response: +1.00230000000000E-007
The following example configures the instrument for 4-digit average period measurements of an approx-
imately 250 MHz signal on channel 2, makes one measurement, and then transfers the measurement to
the instrument output buffer.
MEAS:PER? 4e-9,1e-12,(@2)
Typical Response: +4.03337934613473E-009
See Also
CONFigure?
MEASure:SPERiod?
MEASure:PERiod?
