Leibinger JET3 - Page 135

Group 7 Data/Programming Page 135
Release R1.03e LEIBINGER JET3
Figure 76
Graphiceditor (Delete graphic elements)
1 – Button <Function> 8 – Edit tool <delete>
2 – Drawing tool <Selection> 9 – Button <Function>
3 – Start point (catch frame) 10 – Drawing tool <Selection>
4 – Display <Coordinates> 11 – Start point (catch frame)
5 – Display <Activities to carry out> 12 – End point (catch frame)
6 – End point (catch frame) 13 – Button <Edit>
7 – Button <Edit> 14 – Edit tool <delete>
Areas (elemets)
to delete
6
3
4
8
1
2
9
10
5
7
14
13
12
11
