Step 4

With the front cover open, inspect the two switches. Using a tool, such as

a spring hook, push the metal arms (C) to check the movement.

Is there any damage to the switches or the surrounding area?

Replace the right cover

assembly. See

“Right

cover assembly

removal” on page

232.

Go to step 5.

5027

Diagnostic information

121
