3000167 M3.5 internal lock washer Fuser assembly 1
Top cover 1
3001435
M3x8 screw Lower right frame 1
3003334
3.5x6 mm flat top screw CS410 display bracket 3
CS510 and C2132 UICC card 5
3005980
3.5x8 mm flat top screw Front door 5
3068020
Taptite M3 L4.5 Panhead screw Lower right frame 3
88A0154
M3x8LG W‑HD MCH screw Printhead 3
88A0481
M3.5x8 SEMS MACH screw Fuser assembly 1
Top cover 1
88A0213
Metal ROLN m3.5 8L screw Lower left frame ground cable 1
5027
Appendix E: Screw and retainer identification table
358
