88A0313 Plastic ROLN 2.9 8L screw Toner cartridge contacts 1
CS410 UICC card 5
88A0322
Plastic ROLN 3.5 6L screw AC receptacle 2
Cable cover 5
CS510 and C2132 Display support
bracket
4
Duplex aligner 4
Duplex reference edge 3
Front door 4
CS410, CS510, and C2132 Front USB
connector
2
HVPS 1
Left cover 3
Lower left frame 1
Operator panel 4
CS510 and C2132 Operator panel
back cover
3
CS510 and C2132 speaker 2
Toner meter cycle 2
Toner supply door 1
Top cover 4
Waste toner bottle contact 1
88A0323
Plastic ROLN 3.5 8L screw AC receptacle 2
Duplex aligner 2
88A0324
Plastic ROLN 3.5 10L screw Duplex aligner 2
5027
Appendix E: Screw and retainer identification table
359
