4
Operation
Operation
Function:
LED (5) LED (6)
Transition to standby mode
Illuminates red once
Illuminates green once
Data read-out required - memory 90% full
Flashes red
Illuminates green
Data read-out required - memory 100%
full
Illuminates red
Illuminates green
Power supply active for 60 seconds *) Illuminates yellow Flashes green
*) Depending on the software version, the colours of the LEDs may vary. These LED colours and
additional LED status displays can be checked with the fleet manager.
.
112 Operating Instructions – 3888011701 EN – 12/2017
