Operation
4
Operation
e3861480a
Take note of the switching symbols with
arrows.
1
2
3
4
5
e3861545a
Operating the sideshift
NOTE
In order to prev
ent damage, do not activate
the sideshift
when the fork arms are on the
ground.
Push the joystick (3) forwards.
Sideshift moves to the left.
Pull the joy
stick (3) backwards.
Sideshift moves to the right.
Operating Instructions – 3888011701 EN – 12/2017 137
