Operation
4
Operation
without any load to above the preset lift height
or to above the first stage of the lift mast.
3
Display_e0061a
Effect on the truck:
To prevent the truck from tipping over, the
assistance function intervenes in the lifting and
tilting speed if the load is too great. Depending
on the raised load, the lift height and the tilt
angle, the lifting and tilting speed is reduced or
stopped.
Loading:
Functions
Level I
- Yellow warning light for the assistance system (3) flashes.
- Reduction in the lifting speed.
- Reduction in the tilting speed.
- The buzzer sounds briefly.
Level II
- The red warning light for the assistance system (3) flashes.
- Reduction in the lifting speed.
- Creep speed when tilting forwards.
- The buzzer sounds at short intervals.
Level III
- The red warning light for the assistance system (3) flashes.
- Creep speed when lifting.
- The forwards tilting speed stops.
- The buzzer sounds at short intervals.
Operating Instructions – 3888011701 EN – 12/2017 145
