4
Operation
Drive batteries
Insert the four hooks into the appropriate
openings (2) in the battery tray.
Lift the battery (1).
Drive out of the battery compar
tment.
Set down the battery in a suitable place.
e3861187
1
2
3
Replacing the battery with the truck and a
battery removal tool
WARNING
Risk of accident
Only use trucks and battery removal tools with a
sufficient load capacity.
Pick up the battery removal tool (3) using
theforkarmsofthetruck.
CAUTION
Risk of tipping if the entire battery removal tool is
not lifted.
When picking up the battery removal tool, ensure
that the fork arms protrude from the other end of the
battery removal tool (see arrow).
Drive the truck and battery removal tool
(3) into the battery compartment over the
battery.
Insert the four hook
s into the appropriate
openings (2) in the bat
tery tray.
Lift the battery (1).
Drive out of the battery compartment.
Set down the battery
inasuitableplace.
182 Operating Instructions – 3888011701 EN – 12/2017
