Operation
4
Drive batteries
e3871446
Replacing the battery with the truck and a
battery support (special equipment)
The battery support remains in the truck
underneath the battery tray.
Four covers are fitted (see arr
ows) to protect
the floor area when replacin
g the battery.
CAUTION
The truck floor may be damaged if the fork arms are
not correctly positioned on the covers provided.
Adjust the fork arm distance.
e3871448
The underside of the battery support has four
feet (see arrows), which allow the battery
support with the battery to be set down safely.
CAUTION
The truck floor in the battery compartment may
be damaged if the battery has not been lifted high
enough.
Raise the battery support to a sufficient height to
ensure that the truck can be driven safely out of
the battery compartment.
Operating Instructions – 3888011701 EN – 12/2017 183
