Linde E35 - Page 281

Service work
5
Self-help
Slot
Fuse Value Function
1.1 5F40 15A/32V
Working spotlight positions 1+2
1.2 5F41 15A/32V
Working spotlight positions 3+4
1.3 5F42
*
Working spotlight positions 5+6 or cross beam
1.4 5F43
*
Working spotlights positions 7+8
2.1 9F80 2 A / 32 V
Windscreen wiper (gene
ral)
2.2 9F81 10A/32V
Wash pumps
2.3 9F82 10A/32V
Front windscreen wip
er
2.4 9F83 10A/32V
Rear window and roof panel wipers
9F98 7.5 A / 32 V
Battery carrier
9F102 5 A / 32 V
Fleet Management
Interface 1.0 FMI (CO)
3.1
9F105 10 A / 32 V
Reverse proximi
ty alarm (CO)
9F99 10 A / 32 V
24-V supply (CO
)
9F108 1 A / 32 V
Additional hor
n button with handle, B-pillar (CO)
3.2
9F83 30 A / 32 V
Air conditionin
g(CO)
3.3 9F73 15A/32V
Seat heater
3.4 9F93 15A/32V
12-V socket/Harting socket
8.1 9F94
1A/32V
70-A relay coil for relay (U+ switched)/voltage trans-
former, position 1/2
9F106 5 A / 32 V
4+5auxil
iary hydraulics via special valve (CO)
9F74 10 A / 80 V
Front win
dscreen heating (CO)
8.2
7F1 1 A / 32 V
Oil filte
r monitoring (CO)
6F3 10 A / 32
V
12 V U+ terminal connection
9F101 5 A / 32 V
Camera
system (CO)
4F52 7.5 A /
32 V
Warni
ng lights ON when speed reduction is OFF (CO)
8.3
9F72 10 A / 8
0V
Rear w
indow heating (CO)
