Linde E35 - Page 282

5
Service work
Self-help
Slot Fuse Value Function
6F90
5A/32V
12 V U+ switched terminal connection
5F29
5A/32V
Centre rear sidelight (CO)
8.4
9F75
10 A / 80 V
Roof panel heating (CO)
9.1 5F20
15 A / 32 V
Lighting
5F21
10 A / 32 V
Hazard warning system
9.2
5F27
5A/32V
Hazard warning system for reverse travel with stop light
and without lighting (CO)
9.3 5F26 5 A / 32 V
Brake light lighting
9.4 5F22 7.5 A / 32 V
Left dipped beam
10.1 5F23 7.5 A / 32 V
Right dipped beam
10.2 5F24 5 A / 32 V
Left-hand sideli
ghts
10.3 5F25 5 A / 32 V
Right-hand sidelights
10.4 5F28 2 A / 32 V
Interior lighting/terminal board light
17.1 4F50 7.5 A / 32 V
Rotating beac
on / flashing light / BlueSpot via switch lock
17.2 4F51 7.5 A / 32 V
Switchable reversing signal (warning sound/rotating
flashing light/BlueSpot)
9F95 10 A / 32 V
Radio, U+ switched
17.3
9F95 1 A / 32 V
Screen heating, 80 V (CO)
9F96 5 A / 32 V
Radio, U+
17.4
9F96 5 A / 80 V
Screen heating, 80 V (CO)
18.1 9F91
1A/32V
Relay coil, 70-A relay (U+ switched/voltage transformer,
position 3)
18.2 9F107
10 A / 32 V
Valve for four-stage pressure reduction (CO)
18.3 9F72
15 A / 32 V
R
ear window heating
18.4 9F71
20 A / 32 V
Heater blower
* 7.5-A / 32-V fuse when there is one working spotlight
* 15-A / 32-V fuse when there are two working spotlights
