Service work
5
Self-help
Eight fuse holders, each with four slots, are provided for the fuses for the special electrical equip-
ment. The slot identification is made up of the fuse holder number and the sequential fuse num-
ber, e.g. 17.3. A greater or lesser number of fuse holders can be assigned depending on the truck
model.
.
Fuse colour coding
Fuse
Colour
Fuse
Colour
1A/32V Black 10A/80V* Red
2A/32V
Grey
15 A / 32 V Blue
5A/32V
Light brown
15 A / 80 V * Blue
5A/80V*
Light brown
20 A / 32 V Yellow
7.5A/32V Brown 30A/32V
Green
10 A / 32 V Red
* Note the voltage!
.
Operating Instructions – 3888011701 EN – 12/2017 273
