262334 137 Revision A
NOTE:
High Temperature Extreme Pressure (EP2) Performance With 1% Max Molybdenum Disulphide (NLGI Grade 2) Lithium
Base. To prevent binding and/or excessive wear caused by knife pressing on guards, do NOT over-grease the lubrication
points. If more than 6 to 8 pumps of grease gun are required to fill the cavity, replace the seal in the knifehead.
Figure 4.10: A40D, A40DX Header Left Side
A - Tine Bar Bearing (4 Places Each Tine Bar) (50 Hours) B - Knifehead Bearing (1 Place) (25 Hours)
C - Gauge Roller Bearings (2 Places) Both Sides - If Installed (50 Hours) D - Knife Drive Bearing (1 Place) (50 Hours)
MAINTENANCE AND SERVICING
